103 ADAM-4000 Series User Manual
Chapter 4 Command Set
Table 4.16: ADAM-4024 Command Table
Command Syntax Command Name Command Description Page No.
%AANNTTCCFF Configuration
Set the address, output range, baud
rate, data format, slew rate and/or
checksum status
6-19
#AACn(data) Analog Data Out
Directs output data to a specified
module
6-20
#AASCn(data) Set Startup Data Set data As CHn StartUp Data 6-20
#AAECn(data) Set Emergency Stop
Set data As CHn Emergency Stop
Data
6-20
#** N/A Synchrous Sample IDI 6-20
$AA0Cn 4 mA Calibration
Tells the module to store parameters
for 4 mA Calibration
6-20
$AA1Cn 20 mA Calibration
Tells the module to store parameters
for 20 mA Calibration
6-20
$AA2 Configuration Status Read back Module status 6-20
$AA3Cn(number of
counts)
Trim Calibration
Trims specified module a number of
units up/down
6-20
$AA4
Start-up output cur-
rent/voltage configu-
ration
Stores a default output value in a
specified module. The output value
will take effect upon startup.
6-20
$AA5 Reset Status
Read Back Reset Times After Last
$AA5 CMD And Clear This ounter
6-20
$AA6Cn Last Value Readback
Returns either last value sent to spec-
ified module by #AA command, or
start-up output current/voltage
6-20
$AA7CnRxx Set Output Type Set CHn Output Type 6-20
$AA8Cn Current Readback
Returns measured value of the cur-
rent/voltage flowing through current
loop
6-21
$AAF
Read Firmware
Version
Return the firmware version code
from the specified analog output
module
6-21
$AAM Read Module Name
Return the module name from the
specified analog output module
6-21
$AAACnZ EMS Flag setting
Enable/Disable (Z=1/0)
CHn EMS Flag
6-21
$AABCn Read EMS Flag Read CHn EMS Flag 6-21
$AADCn Read startup data Read Back CHn StartUp Data 6-21
$AAECn
Read emergency
Stop
Read Back CHn Emergency Stop
Data
6-21
$AAG Reset Current Trim
Reset Current Trim Data Variable To
0
6-21
$AAH Read Current Trim Read Current Trim Data Variable 6-21
$AAI Read IDI Read IDI 6-21
$AANCn
Read 4mA Calibra-
tion Parameter
Read Back CHn 4mA Calibration
Parameter
6-21
$AAOCn
Read 20mA Calibra-
tion Parameter
Read Back CHn 20mA Calibration
Parameter
6-21
