ADAM-4000 Series User Manual 122
Table 5.2: ADAM-4015/4015T command codes against Input ranges
table
Command Code (Hex) Input Type Input Range
20 Platinum 100 (IEC) -50 ~ 150 °C
21 Platinum 100 (IEC) 0 ~ 100 °C
22 Platinum 100 (IEC) 0 ~ 200 °C
23 Platinum 100 (IEC) 0 ~ 400 °C
24 Platinum 100 (IEC) -200 ~ 200 °C
25 Platinum 100 (JIS) -50 ~ 150 °C
26 Platinum 100 (JIS) 0 ~ 100 °C
27 Platinum 100 (JIS) 0 ~ 200 °C
28 Platinum 100 (JIS) 0 ~ 400 °C
29 Platinum 100 (JIS) -200 ~ 200 °C
2A Platinum 1000 -40 ~ 160 °C
2B BALCO 500 -30 ~ 120 °C
2C Ni 604 -80 ~ 100 °C
2D Ni 604 0 ~ 100 °C
30 Thermistor 3K 0 ~ 100 °C
31 Thermistor 10K 0 ~ 100 °C
33 Ni 508 -50 ~ 200 °C
IEC RTD 100O,  = 0.00385
JIS RTD 100O,  = 0.00391
Input Range Code (Hex) Input Range for 4019+
02 ± 100 mV
03 ± 500 mV
04 ± 1 V
05 ± 2.5 V
07 +4~20mA
08 ± 10 V
09 ± 5 V
0D ± 20 mA
0E Type J Thermocouple 0 ~ 760 °C
0F Type K Thermocouple 0 ~1370 °C
10 Type T Thermocouple -100 ~ 400 °C
11 Type E Thermocouple 0 ~ 1000 °C
12 Type R Thermocouple 500 ~ 1750 °C
13 Type S Thermocouple 500 ~ 1750 °C
14 Type B Thermocouple 500 ~ 1800 °C
