ADAM-4000 Series User Manual 240
4080, 4080D
7.2.3.5 $AA0L(data)
Name Set Minimum Input Signal Width at Low Level command
Description Set the minimum input signal width at low level for a
specified counter/frequency module to filter noise.
Syntax $AA0L(data)(cr)
$ is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address that you will access to.
0L is the Set Minimum Input Signal Width at Low Level command.
(data) is the minimum width at low level. The unit is in
sec (microseconds) and its resolution is 1 sec. The
format is a five digit integer that can range from 2 sec to
65535 sec. Out of range values will cause errors.
(cr) is the terminating character, carriage return (0Dh).
Response !AA(cr) if the command is valid. The addressed module
stores the value and will identify the input signal “low”
only if the input signal continues to be “low” longer than
the specified time.
?AA(cr) if an invalid operation was entered.
There is no response if the module detects a syntax or
communication error, or even if the specified address does not exist.
! is a delimiter character which indicates a valid command.
? is a delimiter character which indicates an invalid command.
AA (range 00-FF) represents the 2-character hexadecimal
address of the module.
(cr) is the terminating character, carriage return (0Dh).
Example command: $050L00084(cr)
response: !05(cr)
The command requests the counter/frequency module at
address 05 to set the minimum input width at low level to
84 ?sec. The module stores the value and will identify an
input signal to be "low” only if the signal continues to be
“low” longer than 84 sec. This function can be used as digital filter.
