93 AIMB-276 User Manual
Appendix A I/O Pin Assignments
B31 Reserved A31 GND
B32 GND A32 CONFIG2
B33 TX4+ A33 Reserved
B34 TX4- A34 GND
B35 GND A35 RX4+
B36 GND A36 RX4-
B37 TX5+ A37 GND
B38 TX5- A38 GND
B39 GND A39 RX5+
B40 GND A40 RX5-
B41 TX6+ A41 GND
B42 TX6- A42 GND
B43 GND A43 RX6+
B44 GND A44 RX6-
B45 TX7+ A45 GND
B46 TX7- A46 GND
B47 GND A47 RX7+
B48 Reserved A48 RX7-
B49 GND A49 GND
B50 TX8+ A50 Reserved
B51 TX8- A51 GND
B52 GND A52 RX8+
B53 GND A53 RX8-
B54 TX9+ A54 GND
B55 TX9- A55 GND
B56 GND A56 RX9+
B57 GND A57 RX9-
B58 TX10+ A58 GND
B59 TX10- A59 GND
B60 GND A60 RX10+
B61 GND A61 RX10-
B62 TX11+ A62 GND
B63 TX11- A63 GND
B64 GND A64 RX11+
B65 GND A65 RX11-
B66 TX12+ A66 GND
B67 TX12- A67 GND
B68 GND A68 RX12+
