AIMB-276 User Manual 106
A.39 AT/ATX Mode selection (PSON1)
A.40 ATX supported 3-pin header on board
(ATX_5VSB1)
Pin Signal
1VCCAT
2 +V3.3_DUAL
3VCCATX
Pin Signal
1 +V5SB
2GND
3 SPS_PS_ON#
