A.16 CMOS battery connector (BAT1)
A.17 Case Open connector (JCASEOP_SW1)
B69 GND A69 RX12-
B70 TX13+ A70 GND
B71 TX13- A71 GND
B72 GND A72 RX13+
B73 GND A73 RX13-
B74 TX14+ A74 GND
B75 TX14- A75 GND
B76 GND A76 RX14+
B77 GND A77 RX14-
B78 TX15+ A78 GND
B79 TX15- A79 GND
B80 GND A80 RX15+
B81 Reserved A81 RX15-
B82 Reserved A82 GND
Pin Signal
1+VBAT
2GND
Pin Signal
1 CASEOP#(Normal
2 HWM_CASEOP#
3 CASEOP (Normal
