1.5 Board layout: Jumper and Connector Locations
Figure 1.1 Jumper and Connector Location (Top Side)
1.DCIN1 18. JCASEOP_SW1 35. CPUFAN1
2.DP12 19. JCASE1 36. GPIO1
3.HDMI1 20. M2B1 37. JFP1
4.USB78 21. USB910 38. CPU1
5.USB12 22. JSETCOM1_V1 39. DIMMA1/DIMMB1
6.LAN1 23. SATA1~SATA3 40. SPI1
7.USB34 24. COM2 41. SPI_CN1
8.LAN2 25. INV1 42. SATA_PWR1/2
9.USB6 26. COM1 43. PSON1
10.USB5 27. LPC1 44. ATX_5VSB1
11.AUSIO1 28. SIM1
12.AMP1 29. JLVDS_CON1
13.FPAUD1 30. LVDS_EDP1
14.JCOMS1 31. JLVDS1
15.PCIEX16_1 32. SYSFAN1/2
16.PCH1 33. JFP2
17.BAT1 34. JWDT1+JOBS1
