Advantech PCA-684 User Manual

PCA-6184, ed. 1 User’s Manual 106
B.25 PCI Bus Map
Table B.25: PCI bus map
Function AD_Select PCI IRQ GNT
Onboard LAN2 AD22 PCI_IRQ22 GNT3
Onboard LAN1 AD21 PCI_IRQ21 GNT2
Onboard VGA AD20 PCI_IRQ20 GNT1
PCI slot 1 AD31 INT B, C, D, A GNTA
PCI slot 2 AD30 INT C, D, A, B GNTB
PCI slot 3 AD29 INT D, A, B, C GNTC
PCI slot 4 AD28 INT A, B, C, D GNTD
