Advantech PCA-684 - CPU THRM-Throttling; Power on by LAN; Power on by Ring; Power on by Alarm

39
momentarily (for less than 4 seconds) will switch the system to “suspend”
mode.
3.7.6 CPU THRM-Throttling
This field allows you to select the CPU THRM-Throttling rate. The
choices: 12.5%, 25.0%, 37.5%, 50.0%, 62.5%, 75.0%, 87.5%.
3.7.7 Power on by LAN
This item allows you to wake up the system via LAN from the remote-
host. The choices: Enabled, Disabled.
3.7.8 Power on by Ring
When Enabled, an input signal on the serial Ring Indicator (RI) line (in
other words, an incoming call on the modem) awakens the system from a
soft off state. The choices: Enabled, Disabled.
3.7.9 Power on by Alarm
When Enabled, your can set the date and time at which the RTC (real-
time clock) alarm awakens the system from Suspend mode. The choices:
Enable, Disable.
3.8 PnP/PCI Configurations
3.8.1 PnP OS Installed
This features allows you to install the PnP OS. The commands are “yes”
or “no.”
Figure 3.8: PnP/PCI configurations screen
