PCA-6184, ed. 1 User’s Manual 40
3.8.2 Reset Configuration Data
3.8.3 Resources controlled by:
BIOS can automatically configure all the boot and Plug and Play device.
If you choose Auto, you cannot select IRQ DMA and memory base
address fields since BIOS automatically assign them.
3.9 PC Health Status
3.9.1 CPU Warning Temperature
This item will prevent the CPU from overheating. The choices: 30~120.
3.9.2 Current System Temperature
This shows you the current system temperature
3.9.3 Current CPU Temperature
This shows you the current CPU speed.
Note: This is left “Disabled.” Select “Enabled” to reset
Extended System Configuration Data (ECSD) if
you have installed a new add-on card and your
OS won’t boot and you need to reconfigure.
Figure 3.9: PC health status screen
