Advantech PCA-684 User Manual

7
CN20 ATX feature connector
CN21 ATX soft power switch
CN22 HW Monitor Alarm
Close: Enable OBS Alarm
Open: Disable OBS Alarm
CN27 Extension I/O board connector
CN28 Extension I/O board connector
CN29 SM BUS Connector
CN31 USB 0,1
CN32 USB 2,3
CN33 PS/2 Keyboard and Mouse connector
CN34 10/100Base-T Ethernet connector 2
CN46 Auxiliary 4-pin power connector
Table 1.2: Connectors

Advantech PCA-684 Specifications

General

Brand	Advantech
Model	PCA-684
Category	PCI Card
Language	English
