3 PCE-5126 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
CPU: LGA1155-socket Core i7/i5/i3, Pentium and Xeon E3-12XX series proces-
sors
L2 Cache: Core™ i7-2600: Maximum 8 MB
Core™ i5-2400: Maximum 6 MB
Core™ i3-2120: Maximum 3 MB
Pentium® G850: Maximum 3 MB
Xeon® E3-12XX: Maximum 8 MB (Only supported by WG2 version)
BIOS: AMI SPI BIOS (64 Mb SPI)
System Chipset: Intel B65/Q67/C206 platform control hub (PCH)
SATA hard disk drive interface: Two SATA3 (600MB/s) are with blue connec-
tors and four SATA2 (300MB/s) are with black connectors. These interfaces can
be enabled/disabled in the BIOS.
1.3.2 Memory
RAM:
– WG2 SKU: Up to 8 GB in two 240-pin DIMM sockets. Supports dual-channel
DDR3 1066/1333 MHz SDRAM WITH or WITHOUT ECC function.
– QVG and QG2 SKUs: Up to 8 GB in two 240-pin DIMM sockets. Supports
dual-channel DDR3 1066/1333 MHz SDRAM WITHOUT ECC function.
WG2 SKU supports ECC DDR3
1333MHz SDRAM.
To provide higher memory data transmitting reli-
ability, suitable for applications that are sensitive
to system stability such as medical, industrial
server applications.
Fully supports Advantech SUSI APIs and
Utilities.
To reduce customer S/W development effort with
more reliable S/W quality, also provides value-
added utilities such as system monitor and
Embedded Security ID.
SATA Gen3
To provide high performance storage interface.
SATA Gen3 is 6Gb/s which is double bandwidth
with SATA Gen2.
Note! PCE-5126 does NOT support PATA(IDE) interface.
Note! ONLY WG2 SKU support DDR3 memory module with ECC function,
QVG and QG2 can ONLY support those with NO ECC. Wrong memory
configuration may cause no boot or system instability problems.
