PCE-5126 User Manual 4
1.3.3 Input/Output
Backplane Support:
Backplane Support Matrix Table:
PCI bus: Four PCI masters to the backplane, 32-bit, 33 MHz PCI 2.2 compliant.
Enhanced parallel port: This EPP/SPP/ECP port can be configured to LPT1,
LPT2, LPT3 or disabled. A standard DB-25 female connector provided.
Serial ports: Two RS-232 serial ports
PS/2 keyboard and mouse connector:
One 6-pin mini-DIN connectors is
located on the mounting bracket for easy connection to a PS/2 keyboard and
mouse via the Y-cable included in the package.
USB port: Supports up to 13 USB 2.0 ports with transmission rate up to 480
Mbps. 9 ports are on the CPU card and 4 ports are on the backplane.
1.3.4 Graphics
Controller: Intel® HD Graphics embedded in the processor.
Display memory: Max. 1 GB shared video memory with system memory ≥ 2
GB.
CRT: Up to 2048 x 1536 resolution, 400 MHz RAMDAC.
PCI express x16/x8 slot on the backplane: An external graphic card can be
installed in the PCI-E x 16/ x 8 slot for stronger 2D/3D graphic capability.
1.3.5 Ethernet LAN
Supporting single/dual 10/100/1000 Mbps Ethernet port(s) via the dedicated
PCI Express x1 bus which provides 500 MB/s data transmission rate.
Controller:
– LAN 1: Intel® 82579LM for all SKUs.
– LAN 2: Intel® 82583V for QG2 SKU; Intel 82574L for WG2 SKU.
1.3.6 Industrial features
Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels).
1.3.7 Mechanical and environmental specifications
Operating temperature: 0 ~ 60° C (32 ~ 140° F, Depending on CPU)
Storage temperature: -40 ~ 85° C (-40 ~ 185° F)
Humidity: 20 ~ 95% non-condensing
Power supply voltage: +3.3 V, +5 V, +12 V, +5 V
SB
Power consumption: Processor: Intel Core i7-2600; Memory: 2 DDR3 1333
MHz 2 GB DIMMs
Voltage +12 V +5 V +3.3 V +5 V
SB
Current 6.65A 1.62A 1.98A 0.73A
Board size: 338.58 mm (L) x 126.39 mm (W) (13.3" x 4.98")
Board weight: 0.490 kg
Model Backplane
PCE-5126QVG-00A1E PCE-5XXX
PCE-5126QG2-00A1E PCE-5XXX
PCE-5126WG2-00A1E PCE-5XXX and PCE-7XXX (Except PCE-7B10-04A1E)
