v PCE-5126 User Manual
Specification Comparison
Processor Support
Backplane Support Matrix Table
Model Name Memory LAN VGA USB COM
Remote
Management
PCE-5126QVG-00A1E Non-ECC 1 GbE Yes 10 2 SNMP-1000
PCE-5126QG2-00A1E Non-ECC 2 GbE Yes 13 2 SNMP-1000
PCE-5126WG2-00A1E ECC/Non-ECC 2 GbE Yes 13 2 SNMP-1000
Processor PCE-5126QVG-00A1E PCE-5126QG2-00A1E PCE-5126WG2-00A1E
Core i7-2600 Yes Yes -
Core i5-2400 Yes Yes -
Core i3-2120 Yes Yes Yes
Pentium G850 Yes Yes Yes
XEON E3-1275 - - Yes
XEON E3-1225 - - Yes
Backplane
Model
processor
PCE-5XXX PCE-7XXX
PCE-5126QVG-00A1E Yes -
PCE-5126QG2-00A1E Yes -
PCE-5126WG2-00A1E Yes Yes (Except PCE-7B10-04A1E)
Note! If PCE-5126 is used on different backplanes which has different PCIe
configuration. Below message would be showed on first time power on,
and user has to turn off AC power and then turn on for PCIe re-configu-
ration.
Caution! PCIe configuration error! Please turn off AC power before re-configura-
tion.
