PWS-440 User Manual 8
1.3 4-In-1 Battery Charger (Optional)
Item Description
Battery Pack Holder Lock Battery pack into position for Battery charging.
DC IN Jack
Connect the AC adapter to this jack to supply power to the charger
and charge the PWS-440 Battery. *
Status LED
Indicates that power and the PWS-440 battery is charging.
RED light - Battery is charging.
No Light - No battery fitted.
RED light Flash once - Power Adaptor connected, and ready for
charging battery.
Warning! * Both Battery charger adaptor and PWS-440 power adaptor are the
same, but they can NOT be interchanged with other adaptor.
