3 PWS-440 User Manual
Chapter 1 Overview
1.1.2 Package Contents
The standard PWS-440 includes the following items:
PWS-440 PDA unit
Adapter
Battery
Stylus & string
Hand strap
1.1.3 Optional Accessories
In addition the following optional accessories may be included:
Cradle
4 IN 1 Battery Charger
Please carefully check the delivery documents to ensure that all items are present.
In the unlikely event of a discrepancy please contact your supplier.
I/O Ports
Two USB type A connectors, USB1.1 Host (** Two USB Type A at
Left Side)
One USB mini type B connector, USB1.1 Slave (at Right Side
Door)
One RS-232(full) One RS-232/422/485 (OPTION)
One RJ-45 for 10/100M ethernet (USB type)
One stereo headphone jack
One microphone jack
One DC-In connector (At the right side)
One MicroSD Slot
Main Battery
Rechargeable Li-ion smart battery, 7.4V, 1880mAh, 2S1P,
59x38x25mm
Power Adapter Universal AC 90V ~ 265V, 47~63Hz input, 12V, 3.5A output.
Physical 155 x 96 x 42mm, 650g
Environment
Operating Temperature: -20 to +50°C
Storage Temperature -40 to +70°C
Charging Temperature 0 to +50°C
Operating Humidity 5% ~ 95% none condensing
Rugged Specification IP67 5 ft drop to concrete MIL-STD-810G MIL-STD-461E
Certification CE, FCC, CCC
Accessories
1. Case: standard nylon (waterproof) case with belt loop;
2. elastic hand strap: prevent accidental drop
3. Stylus with tether kit
4. Power: DC-Adapter
12 V Vehicle charger with 12 V cable (option)
5. Cradle: 1 x RS-232, 2 x USB (1 x Type A; 1 x TypeB), 1 x DC-
in
6. 4-IN-1 battery charger
Table 1.1: PWS-440 Military PDA Specification
