SUPPLY
Included in the supply are:
1. Machine instructions manual.
2. CE DECLARATION.
3. Threaded ttings for handling.
Keep the manual in a dry place, in order to prevent deterioration,
for at least 10 years for any further reference.
REMOVING FROM THE PALLET
Remove the three screws from support feet.
If necessary, raise the tank insulating material slightly.
Screw the two threaded ttings supplied in the sleeves posi
-
tioned higher.
Handle using means suitable for the weight of the equipment.
The maximum liftable weight per person is 25 kg.
ACCESS TO INNER PARTS
Raise the cover by about 15 cm, taking care not to tear the con-
nection wiring between the card and the unit.
Disconnect the connection cable connector from the control
panel.
Lift the cover up fully to remove it, still being careful of the parts
underneath it.
1
2
3
1. Threaded tting
1
1. Control panel
2. Connection cable
1
2
