BASIC CONNECTION DIAGRAMS
Example of system with SAF°
A. From the heat pump
B. To the heat pump
C. To the DHW distribution system
1. Y-Filter
2. Manometer
3. Safety valve
4. Cut-o valve
5. SAF
6. Circulation pump
7. Expansion vessel
Example of system with integration from replace or boiler for SAF T
A. From the heat pump
B. To the heat pump
C. To the DHW distribution system
1. Y-Filter
2. Manometer
3. Safety valve
4. Cut-o valve
5. SAF T
6. Circulation pump
7. Stove or replace
8. Expansion vessel
9. Filling valve
10. Drain tap
NOT PROVIDED
NOT PROVIDED
NOT PROVIDED
NOT PROVIDED
1
2
A
B
C
3
4
5
4
8
7
6
A
1
2
3
4
5
4
4
2
7
6
6
3
8
9
9
10
4
8
B
C
10
