Agilent InfinityLab LC Series RID User Manual 194
13 LAN Configuration
Manual Configuration
5
Use the “/” and press Enter to list the current settings.
6
Change the IP address (in this example 192.168.254.12) and type “/” to list
current settings.
7
When you have finished typing the configuration parameters, type
exit and press
Enter
to exit with storing parameters.
Figure 44 Closing the Telnet Session
Figure 42 Telnet - Current settings in "Using Stored" mode
information about the LAN interface
MAC address, initialization mode
Initialization mode is Using Stored
active TCP/IP settings
TCP/IP status - here ready
connected to PC with controller software (e.g. Agilent
ChemStation), here not connected
Figure 43 Telnet - Change IP settings
change of IP setting to
Initialization mode is Using Stored
active TCP/IP settings
stored TCP/IP settings in non-volatile memory
connected to PC with controller software (e.g. Agilent
ChemStation), here not connected
If the Initialization Mode Switch is changed now to “Using Stored” mode, the
instrument will take the stored settings when the module is re-booted. In the
example above it would be 192.168.254.12.
