25
Agilent 16901A Logic Analysis System
Service Guide
Agilent Technologies
5
Troubleshooting
To use the 16901A troubleshooting flowcharts 26
To troubleshoot power problems 32
To run the self-tests 35
To restore the system software 37
This chapter helps qualified service personnel troubleshoot
the logic analyzer to find defective assemblies. The
troubleshooting consists of flowcharts, self- test instructions,
and tests. This information is not intended for
component- level repair.
If you suspect a problem, start at the top of the first
flowchart. During the troubleshooting instructions, the
flowcharts will direct you to perform other tests. The other
tests are located in this chapter after the flowcharts.
The service strategy for this instrument is the replacement
of defective assemblies. This instrument can be returned to
Agilent for all service work, including troubleshooting.
Contact your nearest Agilent Technologies Sales Office for
more details.
Electrostatic discharge can damage electronic components. Use
grounded wrist straps and mats when you perform any service to
this instrument or to the cards in it.
