Agilent Technologies 16901A - Page 31

Troubleshooting 5
16901A Logic Analysis System Service Guide 31
Figure 5 16901A Application Troubleshooting Flowchart
5
Reinstall the logic analyzer application.
Replace the MIB board.
Replace the PCI bridge board.
Check all cables to front panel assembly .
Check all cables to CPU motherboard.
Check all cables to MIB board.
Reseat as necessary.
1
1
Try each of the following steps in order.
Return to between each.
A
B
C
D
