Agilent Technologies 16901A Service Guide

Replaceable Parts 7
16901A Logic Analysis System Service Guide 81
Tabl e 3 Replaceable parts for the cover and front panel assembly
Ref.
Des.
Agilent Technologies Part
Number Qty Description
A2 16800-68701 1 Font panel with 15 inch display and touchscreen
H1 0515-0374 Screw-machine M3 x 0.5 10mm long
H2 0515-2032 Screw-machine M3 x 0.5 8mm long 90-deg-flh-hd
H3 0515-0430 Screw-machine M3 x 0.5 6mm long
MP1 01680-68702 1 Accessory pouch
MP2 16800-01201 1 Bracket-front panel
MP4 16901-04101 1 Cover
MP5 54810-61001 4 Foot-bottom
MP6 16800-40503 4 Foot-side
MP7 16800-40201 1 Front frame
MP8 16600-68707 1 Handle assembly (includes screws)
MP9 0950-4805 1 Inverter - DC-AC 8W dual output w/dimming function
MP11 16800-47402 1 Keypad - touchscreen
MP12 16800-66403 1 Keypad PC board assembly
MP13 16702-47402 1 Knob - cursor
MP14 2090-0939 1 LCD (Liquid Crystal Display) 15 inch TFT color
MP15 01680-04701 1 Tilt stand
MP16 0960-2576 1 Touch screen
MP17 0960-2535 1 Touch screen controller board
MP28 16800-01209 1 Front panel plate
