52
3
Front-Panel Menu Operation
This chapter introduces you to the front-panel keys and menu operation.
This chapter does not give a detailed description of every front-panel key
or menu operation. It does, however, give you an overview of the front-
panel menus and many front-panel operations. Refer to the Agilent
33500A Series User’s Guide for a complete discussion of the waveform
generator’s capabilities and operation.
• Front-Panel Menu Reference, on page 53
• To Select the Output Termination, on page 57
• To Reset the Waveform Generator, on page 58
• To Output a Modulated Waveform, on page 59
• To Output an FSK Waveform, on page 61
• To Output a PWM Waveform, on page 63
• To Output a Frequency Sweep, on page 66
• To Output a Burst Waveform, on page 69
• To Trigger a Sweep or Burst, on page 72
• To Store the Instrument State, on page 73
• To Configure the Remote Interface, on page 75
• To Secure and Unsecure the Instrument for Calibration, on page 83
