90
Chapter 4 Calibration and Adjustment
Recommended Test Equipment
4
Recommended Test Equipment
The test equipment recommended for the performance verification and
adjustment procedures is listed below. If the exact instrument is not
available, substitute calibration standards of equivalent accuracy.
* Q = Quick Verification P = Performance Verification T = Troubleshooting
Instrument Requirements Recommended Model Use*
Digital Multimeter
(DMM)
ac volts, true rms, ac coupled
accuracy: ±0.02% to 1 MHz
dc volts
accuracy: 50 ppm
resolution: 100 V
Resistance
Offset-compensated
accuracy: ±0.1
Agilent 3458A Q, P, T
Precision ac
Voltmeter
1000 Hz to 30 MHz
0.1 Vrms to 2 Vrms (–7 dBm to +20 dBm)
accuracy: 0.02 dB
resolution: 0.01 dB
Fluke 5790A Q, P, T
Frequency Meter accuracy: 0.1 ppm Agilent 53132A Opt 012
(high stability)
Q, P, T
Oscilloscope 1 GHz
4 Gs/second
50 input termination
Agilent MSO6104A T
Adapter BNC (m) to dual-banana (f) Agilent 11001-60001 Q, P, T
Adapter N type (m) to BNC (m) Agilent E9623A Q, P, T
Cable (2 required) Dual banana (m) to dual banana (m) Agilent 11000-60000 Q, P, T
Cable RG58, BNC (m) to dual banana Agilent 11001-60001 Q, P, T
Cable RG58, BNC (m) to BNC (m) Agilent 11170C Q, P, T
