Agilent Technologies 34970A Service Guide

Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C350-C351 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C370 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C373 0160-5945 CAP-FXD 0.01uF +-10% 50 V CER X7R 02010 08055C103KATA
C401-C409 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C410 0160-5945 CAP-FXD 0.01uF +-10% 50 V CER X7R 02010 08055C103KATA
CR101-CR104 1901-1375 4 DIODE, 3A, 400V, 75NS,NON-PHOTOSENSITIVE 02037 MURS340
CR105 1906-0407 2 DIODE-FW BRDG 400V 1A 12810 DB104S
CR106-CR107 1902-1609 2 DIODE-ZNR 6.2V 5% PD=1.5W IR=5UA 02037 1SMB5920B
CR108 1902-1512 1 DIODE-ZNR 7.5V 5% TO-236 (SOT-23) 02910 BZX84C7V5
CR109 1906-0407 DIODE-FW BRDG 400V 1A 12810 DB104S
CR110 1906-0291 12 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR183 1906-0291 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR201-CR202 1906-0291 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR301-CR310 1906-0291 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
E102 9170-1584 15 CORE-SHLD BEAD 09808 25Z0805-0SR
E103 1205-0686 3 HEAT SINK SGL TO-220-CS 07179 576802B04000
E105-E106 1205-0686 HEAT SINK SGL TO-220-CS 07179 576802B04000
E120-E124 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
E201 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
E202-E203 9170-1506 2 CORE-MAGNETIC 06352 HF50ACB201209
E204 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
E206-E208 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
E301 9170-1663 1 CORE-SHIELDING BEAD 11702 FBM4532HM132
E315-E318 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
J201 1252-4484 1 CONN-POST TYPE 2.0-PIN-SPCG 12-CONT 03418 52007-1210
J202 1252-8542 1 CONN FRCC VERT MALE 26PIN 04726 2526-6302
J302 1252-2161 1 CONN-RECT MICRORBN 24-CKT 24-CONT 01380 554923-2
MAJ302 2190-0577 2 WASHER- NO. 10 .194-IN-ID .294-IN-OD 02361 2190-0577
MAU101 1205-1178 1 HEAT SINK 02361 1205-1178
MBJ302 2190-0577 WASHER- NO. 10 .194-IN-ID .294-IN-OD 02361 2190-0577
MCJ302 0380-0643 2 STANDOFF-HEX .255-IN-LG 6-32-THD 02361 0380-0643
MDJ302 0380-0643 STANDOFF-HEX .255-IN-LG 6-32-THD 02361 0380-0643
P101 1252-4487 1 CONN-POST TYPE .156-PIN-SPCG 3-CONT 03418 26-64-4030
P102 1252-4488 1 CONN-POST TYPE .156-PIN-SPCG 8-CONT 03418 26-64-4080
P110 1251-5066 1 CONN-POST TYPE 2.5-PIN-SPCG-MTG-END 03418 22-04-1021
7
Chapter 7 Replaceable Parts
34970-66501 Main PC Assembly (A1)
