Agilent Technologies 34970A Service Guide

34970-66504 Internal DMM PC Assembly (A4)
Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C100 0160-6839 1 CAP-FXD 470pF 630 V POLYP-FL 02995 703E1AD471PG631TX
C101-C103 0160-6842 3 CAP-FXD 220pF 630 V POLYP-FL 02995 703E1AD221PG631TX
C104 0160-6497 17 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C105 0160-6731 4 CAP-FXD 1000pF 50 V 02010 12065C102KATA
C106-C107 0160-5967 3 CAP-FXD 100pF +-5% 50 V CER C0G 03292 0160-5967
C108 0160-6736 7 CAP-FXD 0.01uF 50 V 02010 12065C103KATA
C110 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C111 0160-5967 CAP-FXD 100pF +-5% 50 V CER C0G 03292 0160-5967
C113 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C120 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C150 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C151 0160-6736 CAP-FXD 0.01uF 50 V 02010 12065C103KATA
C152 0160-6731 CAP-FXD 1000pF 50 V 02010 12065C102KATA
C160 0160-6736 CAP-FXD 0.01uF 50 V 02010 12065C103KATA
C210 0160-5954 4 CAP 220PF 5% 50V 02010 08055A221JATA
C212 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C301 0160-6778 1 CAP 0.22uF 400 V 05176 HEW-671-220NF+/-10%400V
C302 0160-7605 1 CAP-FXD 1.8pF +-13.89% 1.5 kV CER C0G 02010 MA30SA1R8CAA
C303 0160-6098 1 CAP-FXD 680pF +-5% 50 V CER C0G 02010 12065A681JATA
C304 0160-5973 1 CAP-FXD 6.8pF 50 V 02010 08055A6R8DATA
C305 0160-6096 1 CAP-FXD 470pF +-5% 50 V CER C0G 02010 12065A471JATA
C306 0160-5972 1 CAP-FXD 5.6pF +-8.93% 50 V CER C0G 02010 08051A5R6DATA
C307 0160-5967 CAP-FXD 100pF +-5% 50 V CER C0G 03292 0160-5967
C308-C310 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C313 0160-5955 1 CAP-FXD 68pF +-5% 50 V CER C0G 12473 0160-5955
C314-C315 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C316 0160-5892 2 CAPACITOR-FXD .22UF +-10% 63VDC 05524 MKT1817422065
C317 0160-6729 1 CAP. FIXED. CER./CHIP 02010 12065C332KATA
C318 0160-5892 CAPACITOR-FXD .22UF +-10% 63VDC 05524 MKT1817422065
C319-C320 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C321 0160-5469 1 CAPACITOR-FXD 1UF +-10% 50VDC 10881 BF064D0105KDB
C322-C323 0180-4825 2 CAP-FXD 22uF +-20% 35 V TA 12340 T495X226M035AS
C324 0160-5959 2 CAP-FXD 33pF +-5% 50 V CER C0G 02010 08055A330JATA
C326 0160-6731 CAP-FXD 1000pF 50 V 02010 12065C102KATA
C327 0160-5959 CAP-FXD 33pF +-5% 50 V CER C0G 02010 08055A330JATA
C330 0180-4559 1 CAP-FXD 68uF +-20% 10 V TA 12340 T491D686M010AS
C350-C351 0160-6736 CAP-FXD 0.01uF 50 V 02010 12065C103KATA
C400-C402 0160-5954 CAP 220PF 5% 50V 02010 08055A221JATA
7
Chapter 7 Replaceable Parts
34970-66504 Internal DMM PC Assembly (A4)
191
