Agilent Technologies 34970A Service Guide

34904A 4x8 Matrix
Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C140 0160-7798 1 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C151 0160-5947 1 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C154-C157 0160-5945 12 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C158 0180-4545 1 CAP-FXD 4.7uF +-20% 20 V TA 12340 T491B475M020AS
C164-C165 0160-5967 2 CF 100PF 5% 0805 03292 0160-5967
C166 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C201-C207 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
CR101-CR109 1906-0291 33 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR110-CR111 1906-0395 3 DIODE-DUAL 75V TO-253 02910 BAS28
CR201-CR208 1906-0291 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR301-CR308 1906-0291 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR401-CR408 1906-0291 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR409 1906-0395 DIODE-DUAL 75V TO-253 02910 BAS28
J101 1252-8024 1 CONN-POST TYPE .100-PIN-SPCG-MTG-END 05525 26-8477-048-002-025
J102-J107 0360-2623 6 CONN TERMNAL BK RA FEM 4 PIN 13389 M1.040.0001.8
K101-K108 0490-1896 32 RLY-2C 2A 220V 60WATT 3V-COIL LATCHING 12921 G6SU-2-DC3
K201-K208 0490-1896 RLY-2C 2A 220V 60WATT 3V-COIL LATCHING 12921 G6SU-2-DC3
K301-K308 0490-1896 RLY-2C 2A 220V 60WATT 3V-COIL LATCHING 12921 G6SU-2-DC3
K401-K408 0490-1896 RLY-2C 2A 220V 60WATT 3V-COIL LATCHING 12921 G6SU-2-DC3
L101-L102 9140-1782 2 INDUCTOR 4.7uH +10% -10% 06352 NLC565050T-4R7K
L105-L109 9170-1584 5 CORE-SHLD BEAD 09808 25Z0805-0SR
MP1 34901-60001 KIT, MODULE COVER, CASE 02362 34901-60001
Q101 1855-1101 1 TRANSISTOR 02037 MMDF2P02E
Q111 1853-0525 12 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q113 1854-1053 12 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q121 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q123 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q131 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q133 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q141 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q143 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q211 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Chapter 7 Replaceable Parts
34904A 4x8 Matrix
204
