Agilent Technologies 34970A Service Guide

Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
Q213 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q221 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q223 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q231 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q233 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q241 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q243 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q251 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q253 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q261 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q263 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q271 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q273 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q281 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q283 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
R111 0699-3051 32 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R113 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R121 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R123 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R131 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R133 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R141 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R143 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R147 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R148 0699-3053 1 RESISTOR 100K +-1% .1W TKF TC=0+-100 02995 9C08052A1003FKR
R149 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R151-R152 0699-3034 6 RESISTOR 1K +-1% .1W TKF TC=0+-100 06337 9C08052A1001FKR
R154 0699-3034 RESISTOR 1K +-1% .1W TKF TC=0+-100 06337 9C08052A1001FKR
R155 0699-3061 1 RESISTOR 261 +-1% .1W TKF TC=0+-100 06337 9C08052A2610FKR
R156-R158 0699-3067 3 RESISTOR 14.7K +-1% .1W TKF TC=0+-100 06337 9C08052A1472FKR
R160-R163 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R164-R165 0699-2973 2 RES 215, FIXED THIN FILM 06337 9C08052A2150FKR
R166-R168 0699-3034 RESISTOR 1K +-1% .1W TKF TC=0+-100 06337 9C08052A1001FKR
R211 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R213 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R221 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R223 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R231 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R233 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
7
Chapter 7 Replaceable Parts
34904A 4x8 Matrix
205
