Agilent Technologies 34970A Service Guide

34905A/34906A RF Multiplexer
Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C101-C103 0160-5945 9 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C111 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C140 0160-7798 1 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C151 0160-5947 1 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C158 0180-4545 1 CAP-FXD 4.7uF +-20% 20 V TA 12340 T491B475M020AS
C164-C165 0160-5967 2 CF 100PF 5% 0805 03292 0160-5967
C166 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C201-C204 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
CR102 1906-0291 1 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR170 1906-0395 1 DIODE-DUAL 75V TO-253 02910 BAS28
J101 1252-8024 1 CONN-POST TYPE .100-PIN-SPCG-MTG-END 05525 26-8477-048-002-025
K101-K103 0490-1671 6 RELAY, RG1ET-L-3V 01850 RG1ET-L-3V-H14
K201-K203 0490-1671 RELAY, RG1ET-L-3V 01850 RG1ET-L-3V-H14
For 34905A 50Ω RF Multiplexer:
K101-K103 0490-1672 6 RELAY, 1C 3VDC-COIL 1A 24 VDC 01850 RG1E-L-3V-H13
K201-K203 0490-1672 RELAY, 1C 3VDC-COIL 1A 24 VDC 01850 RG1E-L-3V-H13
L105-L109 9170-1584 5 CORE-SHLD BEAD 09808 25Z0805-0SR
L170-L171 9140-1782 2 INDUCTOR 4.7uH +10% -10% 06352 NLC565050T-4R7K
MP1 34901-60001 KIT, MODULE COVER, CASE 02362 34901-60001
P1-P10 1250-1377 10 CONNECTOR-RF SMB JACK PC-W/O-STDF 50-OHM 03621 5164-5003-09
For 34906A 75Ω RF Multiplexer:
P1-P10 1250-2339 10 CONNECTOR-RF SMB JACK PC-W/O-STDF 75-OHM 03621 131-8701-301
Q101 1854-1053 12 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q102 1853-0525 36 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q103 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q104 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q105 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q106 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q107 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q108 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q109 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q110 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q111 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q112 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q170 1855-1101 1 TRANSISTOR-MOSFET DUAL P-CHAN E-MODE SI 02037 MMDF2P02E
7
Chapter 7 Replaceable Parts
34905A/34906A RF Multiplexer
207
