Module Specifications
34907A
Digital Input / Output
Port 1, 2:
V
in(L):
V
in(H):
V
out(L):
V
out(H):
V
in(H) Max:
Alarming:
Speed
Latency
Read/Write Speed:
8 Bit, input or output, non-isolated
< 0.8V (TTL)
> 2.0V (TTL)
< 0.8V @ Iout = - 400 mA
> 2.4V @ Iout = 1 mA
< 42V with external open drain pull-up
Maskable pattern match or state change
4 ms (max) alarm sampling
5 ms (typical) to 34970A alarm output
95/s
Totalize Input
Maximum Count:
Totalize Input:
Signal Level:
Threshold:
Gate Input:
Count Reset:
Read Speed:
2
26
- 1 (67,108,863)
100 kHz (max), rising or falling edge,
programmable
1 Vp-p (min)
42 Vpk (max)
0V or TTL, jumper selectable
TTL-Hi, TTL-Lo, or none
Manual or Read+Reset
85/s
Analog Voltage (DAC) Output
DAC 1, 2:
Resolution:
I
out:
Settling Time:
Accuracy:
1 year
±5 °C
Temp Coefficient:
±12V, non-isolated (earth referenced)
1 mV
10 mA max
[1]
1 ms to 0.01% of output
±(% of output + mV)
0.25% + 20 mV
±(0.015% + 1 mV) / °C
[1] Limited to 40 mA total for all three slots (six DAC channels)
BenchLink Data Logger
(not included with Option 001)
System Requirements
[1]
PC Hardware:
Operating System:
Computer Interfaces
[2]
GPIB:
LAN-to-GPIB:
RS-232 (Serial Port):
Performance
[3]
Scan and Save to Disk:
486, 66 MHz, 16 MB RAM,
12 MB disk space
Windows
®
3.1, Windows 95,
Windows NT
®
4.0
Agilent 82335B, 82340A/B/C,
82341A/B/C/D
National Instruments AT-GPIB/TNT,
PCI-GPIB
Agilent E5810A (Windows 98/Me/
NT/2000/XP Professional)
PC COM 1 to 4
100 ch/s, 2 strip charts displayed
[1] Software provided on CD-ROM; includes utility to create
floppy disks for installation
[2] Interface and drivers must be purchased and installed separately
[3] 90 MHz Pentium
®
, 20 MB RAM
Software Specifications
Chapter 1 Specifications
Module Specifications
24
