Agilent Technologies 34970A Service Guide

34903A 20-Channel Actuator
Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C101-C104 0160-7798 5 CAP 0.1UF +-10% 50V CER X7R 06352 C2012X7R1H104K
C107 0160-5947 4 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C110 0160-7798 CAP 0.1UF +-10% 50V CER X7R 06352 C2012X7R1H104K
C116-C118 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C120-C127 0160-5967 8 CAP-FXD 100pF +-5% 50 V CER C0G 06352 C2012COG1H101J
C140-C141 0160-5945 9 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C150 0180-4545 1 CAP-FXD 4.7uF +-20% 20 V TA 12340 T491B475M020AS
C201-C207 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
CR102 1906-0395 5 DIODE-DUAL 75V TO-253 02910 BAS28
CR103 1902-1544 1 DIODE-ZNR 10V 5% TO-236 (SOT-23) PD=.35W 02910 BZX84C10
CR201-CR220 1906-0291 20 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR221-CR222 1906-0395 DIODE-DUAL 75V TO-253 02910 BAS28
CR224-CR225 1906-0395 DIODE-DUAL 75V TO-253 02910 BAS28
J101 1252-8024 1 CONN-POST TYPE .100-PIN-SPCG-MTG-END 05525 26-8477-048-002-025
J301-J305 0360-2624 5 CONN TERMINAL BK RA FEM 12PIN 13389 M1.040.0001.9
K208 0490-1896 20 RLY-2C 2A 220V 60WATT 3V-COIL LATCHING 12921 G6SU-2-DC3
K301-K320 0490-1896 RLY-2C 2A 220V 60WATT 3V-COIL LATCHING 12921 G6SU-2-DC3
L101-L102 9170-1663 2 CORE-SHIELDING BEAD 11702 FBMH4532HM132-T
L105 9170-1584 4 CORE-SHLD BEAD 09808 25Z0805-0SR
L109-L111 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
MP1 34901-60001 KIT, MODULE COVER, CASE 02362 34901-60001
Q101 1855-1101 1 TRANSISTOR-MOSFET DUAL P-CHAN E-MODE SI 02037 MMDF2P02E
Q201 1854-1053 14 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q202-Q203 1853-0525 14 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q204 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q205 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q206-Q207 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q208-Q209 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q210 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q211 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q212-Q213 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q214 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Chapter 7 Replaceable Parts
34903A 20-Channel Actuator
202
