Agilent Technologies 34970A Service Guide

Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
Q215 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q216-Q217 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q218 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q219 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q220-Q221 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q222-Q223 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q224 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q225 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
Q226-Q227 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 12125 KST2222A
Q228 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200MW 02237 MMBT2907
R102-R103 0699-3034 12 RESISTOR 1K +-1% .1W TKF TC=0+-100 00746 MCR10-F-X-1001
R105 0699-3034 RESISTOR 1K +-1% .1W TKF TC=0+-100 00746 MCR10-F-X-1001
R106-R109 0699-3051 35 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R110-R112 0699-3067 4 RESISTOR 14.7K +-1% .1W TKF TC=0+-100 00746 MCR10-F-X-1472
R113 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R114 0699-2973 6 RESISTOR 215 +-1% .1W TKF TC=0+-100 06337 9C08052A2150FKR
R115 0699-3067 RESISTOR 14.7K +-1% .1W TKF TC=0+-100 00746 MCR10-F-X-1472
R116-R118 0699-2973 RESISTOR 215 +-1% .1W TKF TC=0+-100 06337 9C08052A2150FKR
R120-R121 0699-2973 RESISTOR 215 +-1% .1W TKF TC=0+-100 06337 9C08052A2150FKR
R122-R127 0699-3034 RESISTOR 1K +-1% .1W TKF TC=0+-100 00746 MCR10-F-X-1001
R140 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R148 0699-3077 1 RESISTOR 1M +-1% .1W TKF TC=0+-100 00746 MCR10-F-X-1004
R149 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
R166-R168 0699-3034 RESISTOR 1K +-1% .1W TKF TC=0+-100 00746 MCR10-F-X-1004
R170-R177 0699-3044 8 RESISTOR 4.64K +-1% .1W TKF TC=0+-100 06337 9C08052A4641FKR
R201-R228 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR
U101 34903-88801 1 PROGMD 1821-1876 MCU N87C52 02632 34903-88801
U102-U104 1820-5752 3 IC FF CMOS/HC D-TYPE POS-EDGE-TRIG COM 02910 74HC574D
U141 1821-0055 1 IC SCHMITT-TRIG CMOS/ACT NAND QUAD 2-INP 02037 MC74ACT132D
U150 1818-6821 1 FRAM SERIAL 4K FMZ4C04-S 14543 FM24C04-S
XU101 1200-1592 1 SOCKET-IC-PLCC 44-CONT SQUARE J-LEAD 01380 3-822499-1
Y101 0410-4009 1 CERO-RES 12MHZ +1-0.8% 00830 PBRC-12.0BRN07
7
Chapter 7 Replaceable Parts
34903A 20-Channel Actuator
203
