34970-66503 Backplane PC Assembly (A3)
Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C109 0160-7438 1 CAP-FXD 0.01uF +-10% 500 V CER X7R 02010 12107C103KATA
E101-E102 1970-0100 2 TUBE-ELECTRON SURGE V PTCTR 11484 1970-0100
J1 1400-0977 1 CLIP BAT 05535 209
L101-L102 9140-1194 2 INDUCTOR 10NH +-10% 2.8W-MMX3.4LG-MM 02366 KL32TE010K
P101-P103 1252-8025 3 CONN DIN VERT MALE 48PIN 02010 16-8477-048-001-025
P104 1252-3442 1 CONN-POST TYPE .100-PIN-SPCG 6-CONT 03418 705-55-0075
P105 1252-3441 1 CONN DIS RA M SPIN SMC 03418 705-55-0074
P106 34970-61611 1 BACKPLANE CABLE 00003 34970-61611
R101 0699-1327 1 RESISTOR 1M +-1% .125W TKF TC=0+-100 04935 9C12063AFKR
R160 0699-4820 1 RESISTOR 220 5% AXIA1 .5W TC=0+200PPM 05524 RNX-3/8N220RJM
RV101-RV102 0837-0509 2 DIO, MOV, OPERV=230VRMS, 17J,
CU4032K230GK1
06121 SIOV-CU4032K230GK1
Chapter 7 Replaceable Parts
34970-66503 Backplane PC Assembly (A3)
190
