Reference

Designator

Part

Number

Qty Part Description

Mfr

Code

Mfr Part Number

R241 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R243 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R251 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R253 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R261 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R263 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R271 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R273 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R281 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R283-R284 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

R287 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 06337 9C08052A1002FKR

U101 34903-88801 1 PROGMD 1821-1876 MCU N87C52 02632 34903-88801

U102-U103 1820-5752 2 IC FF CMOS/HC D-TYPE POS-EDGE-TRIG COM 02910 74HC574D

U111 1818-6821 1 FRAM SERIAL 4K FMZ4C04-S 14543 FM24C04-S

U141 1821-0055 1 IC SCHMITT-TRIG CMOS/ACT NAND QUAD 2-INP 02037 MC74ACT132D

XU101 1200-1592 1 SOCKET-IC-PLCC 44-CONT SQUARE J-LEAD 01380 3-822499-1

Y101 0410-4009 1 CERO-RES 12MHZ +1-0.8% 00830 PBRC-12.0BRN07

Chapter 7 Replaceable Parts

34904A 4x8 Matrix

206

Agilent Technologies 34970A Service Guide
