Agilent Technologies 34970A Service Guide

Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C403-C404 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C407-C408 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C410 0160-6497 CAP-FXD 0.1uF 25 V 02010 12065C104KATA
C441-C442 0160-6736 CAP-FXD 0.01uF 50 V 02010 12065C103KATA
C443 0699-2963 3 RESISTOR 121 +-1pct .1W TKF TC=0+-100 00746 MCR10-FZHM-F-1210
C460 0160-6731 CAP-FXD 1000pF 50 V 02010 12065C102KATA
CR103 1902-1565 1 DIODE-ZNR 4.7V 5% TO-236 (SOT-23) 02910 BZX84-C4V7
CR110-CR113 1901-1607 4 DIODE-PWR RECT 400V DO-214AB 04733 S3G
CR115 1902-1565 DIODE-ZNR 4.7V 5% TO-236 (SOT-23) 02910 12065C102KATA
CR201 1902-1565 1 DIODE-ZNR 4.7V 5% TO-236 (SOT-23) 02910 BZX84-C4V7
CR202 1901-1378 1 DIODE; HV RECTIFIER 1.6KV 04504 GP10Y
CR203 1902-1592 1 DIODE-ZNR 5.1V 5% TO-236 (SOT-23) 02037 BZX84C5V1
CR302-CR303 1906-0291 4 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR304-CR307 1902-1541 5 DIODE-ZNR 3.3V 5% TO-236 (SOT-23) 02037 BZX84C3V3
CR401-CR402 1902-1541 DIODE-ZNR 3.3V 5% TO-236 (SOT-23) 02037 BZX84C3V3
CR403-CR404 1906-0291 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
K102-K104 0490-1896 3 RLY-2C 2A 220V 60WATT 3V-COIL LATCHING 12921 G6SU-2-DC3
L101 9140-1244 2 INDUCTOR 1MH +-5% 3.4W-MMX4.8LG-MM
Q=30
05524 IMC-18121000.0UH+/-5%
L102 9140-1238 3 INDUCTOR 10UH +-5% 2.8W-MMX3.4LG-MM
Q=30
02366 KL32TE100J
L106 9140-1244 INDUCTOR 1MH +-5% 3.4W-MMX4.8LG-MM
Q=30
05524 IMC-18121000.0UH+/-5%
L110-L111 9140-1238 INDUCTOR 10UH +-5% 2.8W-MMX3.4LG-MM
Q=30
02366 KL32TE100J
L401-L402 9170-1431 2 CORE-SHLD BEAD 06352 HF50ACB-453215
L404 9170-1506 1 CORE-MAGNETIC 06352 HF50ACB201209
L405-L407 9170-1584 3 CORE-SHLD BEAD 09808 25Z0805-0SR
P100 34970-61604 1 CABLE, DMM-DGTL 04726 87926-1000T
P101 34970-61603 1 CABLE, DMM-BKPLN 02362 34970-61603
Q104-Q105 1855-0752 2 TRANSISTOR J-FET N-CHAN D-MODE
TO-236AA
03406 MMBF4392
Q150-Q153 1854-1014 4 TRANSISTOR NPN SI TO-236AA PD=350MW 04200 TMPT6429
Q201 1855-0752 TRANSISTOR J-FET N-CHAN D-MODE
TO-236AA
03406 MMBF4392
Q202 1855-1671 1 TRANSISTOR J-FET P-CHAN D-MODE TO-92 02237 ZN5461
Q203-Q210 1853-0727 8 TRANSISTOR PNP SI SOT-23 (TO-236AB) 02237 MMBT6520L
Q211 1855-1672 1 TRANSISTOR J-FET N-CHAN D-MODE TO-92 02237 PN4117A_D26Z
Q301 1855-0800 1 TRANSISTOR MOSFET N-CHAN E-MODE
TO-252AA
02037 MTD3055EL
Chapter 7 Replaceable Parts
34970-66504 Internal DMM PC Assembly (A4)
192
