1 Remove the power cord. Remove the
fuse-holder assembly from the rear panel.
2 Remove the line-voltage selector from
the assembly.
3 Rotate the line-voltage selector until the
correct voltage appears in the window.
4 Replace the fuse-holder assembly in
the rear panel.
Verify that the correct line voltage is selected and the power-line fuse is good.
Fuse: 500 mAT (for all line voltages)
Agilent Part Number: 2110-0458
100, 120 (127), 220 (230) or 240 Vac
2
Chapter 2 Quick Start
If the Instrument Does Not Turn On
43
