Site Preparation
Benchtop space requirements
6
Figure 1. Common GC system configurations—top views
59* cm
50 cm
50 cm
47 cm
54 cm
44 cm
40 cm
28 cm
23 cm
65 cm
17 cm
GC
59* cm
50 cm
10 cm
31 cm
GC with Agilent Automatic Liquid Sampler
GC with Agilent ChemStation
GC with 5972A Mass Selective Detector
*68 cm for non-EPC version.
Tray—30.3 cm
left of GC
ALS Controller
Injector—44 cm
above GC
Computer
Keyboard
GC
Mouse
pad
Printer
GC
7673
59* cm
