Agilent Technologies 6890 Series - USA Fast Heating Oven

Site Preparation
Electrical requirements
10
Table 3. Voltage Requirements by Country
USA fast heating oven
The fast heating oven requires 240 V/15A power. Do not use 208 V power. Lower
voltage causes slow oven ramps and prevents proper temperature control. The
power cord supplied with your GC is rated for 250 V/15A, and is a two pole, three
wire cord with grounding (type L6-15R/L6-15P). See the figure below.
Country Voltage Oven type
Australia, 10 amp 240 V Slow–heating
Australia, India, South Africa 240 V Fast–heating
China 220 V Slow–heating
China, Hong Kong 220 V Fast–heating
Continental Europe, dual phase 230 V Fast–heating
Continental Europe, single phase 220 V Fast–heating
Denmark, Switzerland, 10 amp 230 V Slow–heating
Denmark, Switzerland, 16 amp 230 V Fast–heating
Israel 220 V Fast–heating
Japan 200 V Fast–heating
United Kingdom, Ireland 240 V Fast–heating
USA 120 V Slow–heating
USA 240 V Fast–heating
Receptacle
L6-15R
Plug
L6-15P
