7
Site Preparation
Benchtop space requirements
Table 1. Dimensions, Power, Heat Production, and Weight
Instrument Height Width Depth Power (VA) Heat Weight
6890 Gas Chromatograph
EPC version 54 cm
21 inch
59 cm
23 inch
54 cm
21 inch
2,250 8,100 KJoules
7,681 Btu/hr
50 kg
112 lb
Non-EPC version 51 cm
21 inch
68 cm
26.7 inch
54 cm
21 inch
2,250 8,100 KJoules
7,681 Btu/hr
56.8 kg
125 lb
Fast heating oven,
same for EPC and non-EPC
2,950 10,620 KJoules
10,071 Btu/hr
GC Automatic Liquid Sampler
G1512A Controller (7673) 10 cm
4inch
33 cm
13 inch
38 cm
15 inch
320 max 545 KJoules
515 Btu/Hr
7.3 kg
16.0 lb
G1513A or G2613A Injector 44 cm above GC
17 inch above GC
18596 or G2614A Tray 30.3 cm left of GC
9 inch left of GC
Computer*
Computer with monitor 54 cm
21 inch
42 cm
17 inch
39 cm
15 inch
N/A N/A N/A
Keyboard 5cm
2inch
47 cm
18 inch
18 cm
7inch
N/A N/A N/A
5972A Mass Selective
Detector
35 cm
13.6 inch
17 cm
6.7 inch
65 cm
25.6 inch
254 max 3,158 Btu/hr,
3,000 with GC
22.7 kg
50.0 lb
7694 Headspace Sampler 31 cm
16 inch
56 cm
22 inch
39 cm
22 inch
420 max 2,215 KJoules
2,100 Btu/hr
35.8 kg
79.0 lb
Printers
Laser printer 30 cm
11.7 inch
42 cm
16.4 inch
40 cm
15.9 inch
300 max N/A 16.8 kg
37.0 lb
Integrators
3397 Series,
3396 Series III and,
3395 Integrators
13 cm
4.5 inch
46 cm
18 inch
46 cm
18 inch
50 135 KJoules
120 Btu/hr
4.3 kg
9.5 lb
35900C/D/E Analog-to-
Digital Converter
11 cm
4inch
33 cm
13 inch
29 cm
11 inch
40 216 KJoules
205 Btu/hr
4.1 kg
9.0 lb
* General specifications for a mid-size, desktop computer
