Agilent Technologies 7200 Troubleshooting And Maintenance Guide

114 Troubleshooting and Maintenance Manual
7 Replacement Parts
Collision cell board G7000-65814
4.0 GHz Acquisition board G1969-61004
Motherboard, 1 GHz, 1 GB memory 0960-2490
SDRAM, 256 MB 1818-8947
PLX board G2571-61001
Main board G7005-61105
Smart card 7 G3850-67420
PCA, electrometer, tested G3850-67002
PCA, Fuse board, tested G3850-67005
PCA, status light, tested G3850-67014
PCA, side board, tested G3850-67015
PCA Q-TOF turbo 2,3 adapter, tested G3850-67020
Log amp G3170-65101
Extender board, PCI, 32 bit 0403-1169
Table 9 Power supplies and related parts
Description Part number
Toroid transformer G7000-60229
Power supply, AC/DC, 4 output G3850-80001
AC PCA, PV Pump w/gage G1960-61117
Smartcard 7 tray assemblies G3850-67420
48V power supply G3850-67600
ATX power supply G3850-67601
Imaged 160GB hard disk G3850-67603
Table 8 Printed circuit boards (continued)
Description Part number
