Replacement Parts 7
Troubleshooting and Maintenance Manual 121
Analyzer
Table 14 shows the analyzer chambers and associated parts.
Table 15 shows the replacement parts for the analyzers. Analyzer screws
(Table 16) and the individual ion source parts (Table 17) are listed in the
tables that follow.
Table 1 4 Analyzer chamber and related parts
Description Part number
Micro Ion Gauge G1960-80303
Ion gauge baffle G7000-20049
O-ring 0905-1627
M3x12L screws 0515-0664
EI Calibration valve assembly G3850-67204
Calibration vial G3170-80002
Side plate (includes feedthrough and thumbscrews) G7000-60021
Collision cell holder G3850-20042
Table 1 5 Analyzer parts
Description Part number
RFI gasket, side G7000-80101
Magnet assembly 05971-60160
Low gauss magnet assembly G3163-60560
Source PCA and cable assembly G7005-67425
Mass filter cable kit G3170-60130
Mass filter contacts (4) G1099-60142
Mass filter canted coil support, detector end G3170-20025
Mass filter canted coil spring G1460-2724
