130 Troubleshooting and Maintenance Manual
7 Replacement Parts
RIS Manifold
Table 2 0 RIS Manifold
Description Part number
RIS manifold assembly G7005-67100
Gate valve extension cable G3850-60839
Gate valve G7005-67010
Restrictor assembly G7005-67015
RIS convection vacuum gauge assembly G7005-67158
Gauge adapter G7005-20165
Frame G7005-00001
Gasket G7005-40015
Inner window G7005-20552
RIS control valve G7005-60009
RIS rear manifold support assembly G7005-67159
RIS probe manifold support assembly G7005-67160
Dust cover G7005-20155
Relief valve, 1psi 0101-1457
Hinge bushing G7005-20157
Catch housing G7005-20011
Catch knob G7005-20010
Catch pin G7005-20009
RIS front manifold G7005-20158
Screw, pan with washer, T10 M3x10MM-lg 0515-0666
O-ring, 0.239 inch id, 0.07 in xsect diameter 0905-1014
O-ring, 2.239 inch id, 0.07 in xsect diameter 0905-1131
