132 Troubleshooting and Maintenance Manual
7 Replacement Parts
GC/MS Interface
Table 21 lists the replacement parts related to the EI GC/MS interface.
Table 2 1 EI GC/MS interface
Description Part number
GC/MS interface (complete) G7005-60400
RIS Transfer line G7005-67400
Interface Self Tightening column nut 5190-5233
Interface column nut 05980-20066
Heater clamp G7005-20410
Heater/Sensor assembly G7005-60107
Insulation G7005-20403
Setscrew for heater/sensor assembly 0515-0761
Screws, M2x0.4 0515-2151
CI braze assembly G7005-67401
Spring, transfer line G7005-20024
Inner cup tube G7005-20026
Inner cup cap G7005-20028
RIS transfer tip G7005-67542
RIS transfer tip cap G7005-67543
Cylinder drive G7005-20108
Screw, machine M3x0.5, 6mm lg 0515-0403
Ferrule, 1/16 no hole, graphitized vespel 0100-0690
Screws for mounting interface and cover to analyzer
chamber
0515-0380
