122 Troubleshooting and Maintenance Manual
7 Replacement Parts
Mass filter ceramic support, source end G1099-20123
Mass filter heater assembly G7005-67107
Pins for source and detector end mounting
brackets
G1099-20137
Entrance lens G7005-67126
Quad mount grnd quad G7000-20025
Analyzer with extractor assembly, tested G7005-67201
Analyzer with extractor assembly, rebuilt G3850-69201
p-filter bridge G7000-60028
Extraction source socket housing assembly G7005-67091
Lens sleeve G7005-67135
Wire, RIS heater G7005-60811
Wire, RIS sensor G7005-60812
Wire, RIS body G7005-60813
Side plate, MS1 G7000-60021
Table 1 6 Analyzer screws
Description Part number
Heater/Sensor (quad) setscrew G1099-60172
Ion source thumbscrew G1099-20138
Magnet mounting screws 0515-1046
Screw – magnet bracket to source radiator 0515-1602
Screws – mass filter contact assembly/heater block G3170-20122
Screws – radiator. Mounting brackets quadrupole
board
0515-0430
Table 1 5 Analyzer parts (continued)
Description Part number
RFI gasket, side G7000-80101
