Replacement Parts 7
Troubleshooting and Maintenance Manual 123
EI source
Source radiator screws 0515-1052
Screws for Quad Stop 0515-0221
Table 1 6 Analyzer screws (continued)
Description Part number
Table 1 7 Inert RIS EI Extractor Ion Source Assembly (Figure 22)
Description Part number
Inert RIS ion source assembly G7005-67700
10 Ion focus insulator G7005-67442
12 Ion focus pins G7005-67444
16 RIS EI Repeller cap G7005-67043
2 RIS EI Repeller G7005-67044
4 Repeller insulator G7005-67447
9 Clocking button G7005-20046
15 EI 4-turn filament, ground G7005-60053
3 Bayonnet catch G7005-20446
14 Ring heater G7005-67110
11 Ion focus lens G7005-67443
1 Extractor lens insulator G7005-67133
13 Extractor lens G7005-67132
Screws for filament G1999-20021
6 Washer, spring curved 3050-1374
5 Screw (M2x6L), clocking button 0515-0221
Screw (M2x12L) 0515-1047
8 Screw, bayonet mount 0515-5276
