126 Troubleshooting and Maintenance Manual
7 Replacement Parts
CI source
Table 1 8 RIS CI ion source (Figure 23)
Description Part number
RIS CI source assembly, tested G7005-67750
2 RIS CI bayonet catch G7005-67212
10 Screw, long 0515-5276
12 RIS CI filament G7005-80053
RIS transfer tip G7005-67542
RIS transfer tip cap G7005-67543
8 Ion focus lens G7005-67443
7 Ion focus lens insulator G7005-67442
9 Ion focus pin G7005-67444
1 RIS CI repeller G7005-67211
3 RIS CI repeller insulator G7005-20030
6 Clocking button G7005-20046
4 Screw 0515-0221
13 Ring heater G7005-67110
5 Screw-set, M3x3L, gold plated G1999-20022
14 RIS CI Source body G7005-67210
RIS CI ion source bottle assembly G7005-67005
11 Washer-spr CRVD 1.6 1.8-MM-ID, 4-MM-OD, SS 3050-1374
