128 Troubleshooting and Maintenance Manual
7 Replacement Parts
RIS Probe Extraction Tool Assembly
Table 1 9 RIS probe extraction tool assembly (Figure 24, and Figure 25)
Description Part number
RIS probe extraction tool, complete cooling chamber
assembly
G7005-65000
RIS probe maintenance kit G7005-67170
11 RIS cooling chamber G7005-67156
6 Probe shaft G7005-67014
12 Bayonet tip G7005-67177
13 Seal cartridge assembly G7005-60070
2 Fastener, strike with compression spring 1390-1387
Wave spring 1460-20014
14 Canted coil spring G7005-80105
Retainer ring, internal 0510-1833
1 Probe cap G7005-20152
10 Screws, M3x20mm 0515-5384
4 Screw, machine with washer pan 0515-0372
3 Screw, machine 90 degree 0515-1602
8 Bayonet plunger G7005-67178
7 Probe handle G7005-20175
