Install the Configuration Plug
Before use, set the HS power configuration.
Verify the available power configuration
1 Locate the configuration plug that shipped with the
headspace sampler. Compare the voltage shown on the
configuration plug label with the laboratory line voltage.
(For customers in Japan using 100 VAC, the unit is
120 VAC with an external 100 V/200 V step up
transformer.) See Table 5.
2 Locate the power cord that shipped with the headspace
sampler. Verify the power cord is correct for the locale
and voltage.
Measure the power outlet voltage and verify it meets the
tolerance requirements listed in Table 6.
Table 5 Headspace sampler power configuration plugs
Part number Voltage Color
G4556-60390 120 VAC Brown
G4556-60400 200 VAC Red
G4556-60410 220 VAC Orange
G4556-60420 230 VAC Yellow
G4556-60430 240 VAC Violet
Measuring the mains voltage can expose you to hazardous
electrical current. Only a trained technician should perform this
step.
