Attach the transfer line to a GC inlet
Split Splitless or Multimode Inlet
1 Slide the one- piece septum nut and strain relief coupling
onto the tubing until the inner metal sleeve of the
transfer line bottoms- out on the strain relief.
2 Slide the septum onto the tubing until the septum is
against the bottom of the one- piece septum nut and
strain relief coupling.
3 Trim the tubing 35 mm past the end of the septum.
4 Install the inlet liner (with o- ring) that is appropriate for
your application.
5 Insert the tip of the transfer line into the inlet.
6 Finger- tighten the strain relief coupling.
Purged Packed Inlet
1 Slide the one- piece septum nut and strain relief coupling
onto the tubing until the inner metal sleeve of the
transfer line bottoms- out on the strain relief.
2 Slide the septum onto the tubing until the septum is
against the bottom of the one- piece septum nut and
strain relief coupling.
3 Trim the tubing 2 mm past the end of the septum.
4 Install the inlet liner (with o- ring) that is appropriate for
your application.
5 Insert the tip of the transfer line into the inlet.
6 Finger- tighten the strain relief coupling.
Wear clean, lint-free gloves to prevent contamination of parts with
dirt and skin oils.
Be careful! The oven and/or inlet may be hot enough to cause
burns. If either is hot, wear heat-resistant gloves to protect your
hands.
