Agilent Technologies 7697A Installation And Startup Guide

44 Installation and First Startup
1 Installation
15
Gently slide the tubing into the internal reducer until it
bottoms. Tighten the 3/16- inch nut finger tight, then an
additional 1/4- turn. Test the connection by gently pulling
on the transfer line. The transfer line should not slide out
of the newly- made fittings. See Figure 14.
Figure 14 Transfer line installed into 6 port valve
